Factory direct sales 300-360kw commercial charging pile new energy electric vehicle fast charging station
Product name : Factory direct sales 300-360kw commercial charging pile new energy electric vehicle fast charging station
Model No. : 24011001
Price : 7400$/set-10200$/set
Products Category: > EVs Charging pile
Factory direct sales 300-360kw commercial charging pile new energy electric vehicle fast charging station
Product number | ZD300-1 | ZD360-1 |
AC input voltage | Three-phase AC380V(A/B/C+N+PE)±15% | |
AC input current | ≤455A | ≤546A |
Maximum output power | 300kW 360kW | |
DC output voltage | 200~750V | |
DC output current | Maximum 500A | |
Display | 7-inch high-brightness touch screen | |
way of communication | 4G/Ethernet/standalone | |
charging method | Password startup, card swipe startup, code scan startup, VIN code startup | |
Full load conversion efficiency | ≥95.5% | |
allowable operating temperature | -20~+50℃ | |
allowed relative humidity | 0~95% (no condensation) | |
cooling method | Forced air cooling | |
Auxiliary power | 12V/24V can be set to switch | |
Protection level | IP54 | |
Product Size | 1936*1000*903mm | |
weight | ≤350kg |
Advantages:
1. Easy to install and operate
2.7-inch high-brightness touch screen
3. Vehicle socket: common to all electric vehicles
4. Charging method: password start, card swipe start, code scan start, VIN code start
Waterproof, low temperature protection, short circuit protection, overvoltage/undervoltage protection, leakage protection, lightning protection
Charging gun:
Silver clad copper alloy
High conductivity
High temperature resistance
thermoplastic
Insulator flame retardancy UL94V-0
Our charging piles support customization
Standard export packaging display
Company Profile
Shandong E-Valley Intelligent Manufacturing Co., Ltd. is located opposite the south gate of Xiangkai Logistics Park, Xiajin County Economic Development Zone, Dezhou City, Shandong Province. It is a subsidiary of Shandong Xutong Group, which is a company integrating logistics, transportation, gas stations, and automobiles. A full-service enterprise that integrates repair shops, logistics parks, supermarkets, motor vehicle testing, motor vehicle driver training, automobile sales and other industries, Xutong Group is a sincere, pragmatic and innovative service that "emphasis on quality, integrity and the most assured".
E-Valley is an Internet of Things high-tech enterprise integrating R&D, production and marketing of smart charging piles. It deeply integrates traditional charging piles with key technologies such as electronic automation, big data, cloud computing, blockchain, and 5G. Establish a Shandong digital energy supply chain cloud platform to provide customers with industry-leading one-stop solutions for intelligent charging systems, and provide government agencies with big data access and cloud platform development services. E-Valley will continue to explore the innovative integration of digital technology and energy technology, deeply explore user needs, and establish a comprehensive service platform for new energy industry commerce, finance, insurance, etc., to assist the digital upgrading and development of the industry.
FAQ
A. How to place an order.
1. Contact customer service to confirm details such as freight and product model,Configuration, quantity, etc. (you can also arrange freight forwarding by yourself).
2. We provide you with a Proforma Invoice with all product details based on your final decision.
3. Usually you need to arrange 30% payment to our bank account, then we will prepare the products.The cycle is generally about 10-15 days, and the specific delivery can be determined according to your order quantity.
4. After the product is completed, pay the balance, and we will arrange the freight forwarder to deliver the goods (or we will provide relevant information and arrange the freight forwarder transportation by ourselves).
5. After completing this process, the customer service will track the location of the product and notify you when it is approaching and arriving, so that you can quickly prepare for customs clearance and other related matters.
6. After receiving the item, there will be a dedicated after-sales team waiting for your follow-up feedback.
B. Why choose us?
1. We can provide consistent, high-quality products.
2. We can provide high-quality and fast customer service If you have any other questions, please feel free to contact us.
3. Our competitive and reliable product prices.
C. What is your minimum order quantity?
1 unit, however, we offer better discounts for large orders.
